The Outdoor Plus Cabo Square Fire Pit (Powder Coat) Features
- Clean, Modern Square Design: The Cabo's crisp, architectural lines make it a versatile centerpiece for patios, pool decks, and upscale outdoor entertaining areas.
- Durable Powder-Coated Steel Construction: A premium powder coat finish resists chipping, fading, and corrosion, keeping the fire pit looking sharp with minimal upkeep.
- Available in Three Sizes: Choose from 36", 48", or 60" to fit the scale of your space, all delivering the same strong heat output.
- 65,000 BTU Output: Every size in the Cabo Square lineup is rated for a consistent 65,000 BTU/h, providing plenty of warmth and flame presence for evening gatherings.
- 304 Stainless Steel Pan and Burner: The internal fire pan and burner ring are built from 304 stainless steel for long-term reliability and resistance to rust.
- Weather-Ready Drainage: A standard 1" flange and 2" pan depth pair with built-in drain holes, so rainwater clears out instead of pooling in the pan.
- Choice of Ignition Systems: Available with Match Lit, Match Lit with Flame Sense (LC certified), Flame Sense with Spark, Low Voltage Electronic (CSA certified), or Plug and Play (CSA certified) ignition to match your preferred setup.
- Seven Powder Coat Colors: Offered in Black, Copper Vein, Java, Pewter, Silver Vein, Smooth Gray, and White to complement any outdoor palette.
- Runs on Natural Gas or Liquid Propane: Configurable for either fuel type to match your existing gas line or propane setup.
- Handcrafted in the USA: Individually made to order at The Outdoor Plus's Ontario, California facility, with minor natural variation in texture and finish expected.
Please note: Each Outdoor Plus product is made to order, therefore all sales are final. All complete items have a lead time of 4-5 weeks.
48" Cabo Square Fire Pit Table Instruction Manual:
Cabo Square Natural Gas Fire Pit Specification Sheet:
The Outdoor Plus Cabo Square Fire Pit (Powder Coat) Specs
| Fire pit material | Powder-coated steel |
| Pan material | 304 stainless steel |
| Burner material | 304 stainless steel |
| Maximum heat output (all sizes) | 65,000 BTU/h |
| Available sizes | 36", 48", 60" |
| Overall footprint - 36" model (W x D x H) | 36" x 36" x 16" |
| Overall footprint - 48" model (W x D x H) | 48" x 48" x 16" |
| Overall footprint - 60" model (W x D x H) | 60" x 60" x 16" |
| Base dimension - 36" model | 24" x 24" |
| Base dimension - 48" model | 36" x 36" |
| Base dimension - 60" model | 48" x 48" |
| Burn/opening area - 36" model | 20" x 20" |
| Burn/opening area - 48" model | 28" x 28" |
| Burn/opening area - 60" model | 40" x 40" |
| Burner size - 36" / 48" / 60" | 12" / 18" / 24" |
| Pan flange / depth | 1" standard flange, 2" standard pan depth |
| Available colors | Black, Copper Vein, Java, Pewter, Silver Vein, Smooth Gray, White |
| Fuel type | Natural gas or liquid propane |
| Ignition options | Match Lit; Match Lit with Flame Sense (LC certified); Flame Sense with Spark; Low Voltage Electronic (CSA certified); Plug and Play (CSA certified) |
| Match Lit unit includes | Pan, burner, gas orifice, gas hoses, key valve, key |
| 110V electronic ignition unit includes | Pan, burner, gas orifice, gas hoses, key valve, key, plug & play electronic valve, pilot igniter |
| Certifications | ANSI Z21.97-(2017) / CSA 2.41-(2017) |
| Warranty - fire pit body (powder coat) | 1 year |
| Warranty - stainless steel pan | 5 years (residential) |
| Warranty - burner ring & burner bars | Lifetime |
| Warranty - gas valve & pilot assembly | 1 year (residential) |
| Construction | Handcrafted, made to order in Ontario, California, USA |
The Outdoor Plus Cabo Square Fire Pit (Powder Coat) FAQ
How weather-resistant is the powder coat finish?
The powder coat finish is built to resist chipping, fading, and corrosion outdoors. That said, The Outdoor Plus recommends using a stainless steel or canvas cover when the fire pit isn't in use, since keeping it covered helps protect the finish and extends its lifespan.
What maintenance does the Cabo Square Fire Pit need?
Routine care is minimal: wipe down the powder-coated surface periodically, keep the drain holes in the pan clear, and cover the unit when it's not in use to protect it from prolonged exposure to rain and sun. Avoid abrasive cleaners on the finish.
What warranty comes with this fire pit?
The powder-coated fire pit body carries a 1-year warranty against manufacturing defects. The stainless steel pan is separately warrantied for 5 years (residential use), the burner ring and bars carry a lifetime warranty, and the gas valve/pilot assembly is covered for 1 year. The warranty is non-transferable and applies to the original owner only.
Does the Cabo Square Fire Pit require professional installation?
Gas line connection and ignition system installation should be handled by a qualified professional in accordance with local codes. Installation manuals are available for each ignition type to guide the setup process.
Is this fire pit suitable for commercial use?
Yes, the Cabo Square is available for both residential and commercial settings, though note that warranty coverage periods differ between residential and commercial use—commercial coverage is generally shorter than residential coverage.
What size should I choose?
All three sizes (36", 48", 60") share the same 65,000 BTU output, so the choice mainly comes down to the scale of your outdoor space and how large a flame footprint you want. Larger sizes offer a bigger burn area and base footprint for larger patios or gathering spaces.
What ignition system should I pick?
Match Lit is the simplest and most affordable option. Flame Sense variants add safety shutoff features, while Low Voltage Electronic and Plug and Play ignitions offer push-button convenience and are CSA certified. Choose based on your desired convenience level and local code requirements.
Can I run this fire pit on natural gas or propane?
Yes, the Cabo Square is available configured for either natural gas or liquid propane, so it can be set up to match your existing outdoor gas line or a propane tank setup.
