VORTEX DOUBLE WALL 7" TO 6" REDUCER VOD0250

The reducer must be installed with the male end (7" diameter) pointing downward and the female end (6" diameter) pointing upward. This configuration ensures proper draft and prevents smoke leakage. Secure all joints with at least three #8 x 1/2" self-drilling screws per connection to ensure a tight, safe seal.

No, this reducer is designed to work exclusively with Vortex Double Wall connector pipe and listed Vortex components. Mixing manufacturers' products can compromise safety certifications, create improper fits, and void warranties. Always use matching Vortex components throughout your entire venting system for optimal performance and safety compliance.

The Vortex double-wall construction allows for reduced clearances of 6 inches to combustible side walls and 8 inches to combustible ceilings (including cathedral ceilings). This is significantly safer than single-wall pipe which requires 18 inches clearance. However, always verify that your specific wood stove's clearance requirements are also met, as appliance clearances must be maintained separately.

The double-wall air-insulated design maintains higher flue gas temperatures, creating stronger draft for improved stove performance and efficiency. The thermal weave stainless steel inner wall promotes even airflow while keeping outer wall temperatures cooler for safety. This design also heats up faster, stays hot longer, and significantly reduces creosote formation compared to single-wall pipe.

While there's no absolute limit per NFPA 211 and CSA B365 standards, Vortex recommends a maximum total system length of 15 feet when using offsets (elbows), or up to 20 feet for straight vertical runs without offsets. Longer runs may affect draft performance. Ensure all sections are solidly fastened together and properly supported according to installation instructions.

Yes, double-wall stove pipe like the Vortex VOD0250 is required for manufactured home installations due to its reduced clearance capabilities and enhanced safety features. The product meets UL 103 HT standards which specifically address manufactured housing requirements. Always consult your appliance manufacturer's installation instructions and local codes for complete compliance.

Inspect the reducer annually before heating season for any signs of corrosion, damage, or loose connections. Check that all screws remain tight and secure. Clean the interior if creosote buildup is present using appropriate chimney cleaning tools. The powder coat finish should be checked for chips or wear, and the laser-welded joints should be examined for integrity. Replace the component if any structural damage is detected.

The Vortex VOD0250 comes with a manufacturer's warranty that covers defects in materials and workmanship. The warranty is only valid when the product is installed according to the provided instructions using compatible Vortex components exclusively. Improper installation, mixing with other brands, damage from over-firing, or failure to maintain proper clearances will void the warranty. Contact your retailer or manufacturer for specific warranty terms and duration.
