3" PELLET BLACK WALL PASS-THRU WITH FRESH AIR INTAKE VOP0262

The fresh air intake provides dedicated outside combustion air directly to your pellet stove, which offers several significant advantages: improved combustion efficiency, elimination of negative indoor air pressure that can cause drafting problems, reduced heating costs, prevention of backdrafting from other appliances, and maintaining better indoor air quality by not depleting oxygen from living spaces. This is especially valuable in modern, tightly sealed energy-efficient homes.

Yes, the VOP0262 is designed with adjustable components that accommodate wall thicknesses ranging from 4 to 9 inches. This versatility makes it compatible with standard wood-frame construction (typically 3.5" or 5.5" studs plus interior and exterior finishes), insulated walls, and even thicker wall assemblies. Always measure your actual wall thickness before installation to ensure proper fit and order any necessary extension components.

The VOP0262 includes integrated weather protection features with exterior trim plates designed to shed water away from the penetration. For optimal weatherproofing: ensure proper flashing installation under and over the trim plate, use high-quality exterior sealant around all exterior trim edges, verify that the trim plates overlap properly with your siding or exterior finish, and maintain adequate clearances as specified in the installation manual. Consider using a siding trim kit for vinyl or aluminum siding installations to achieve the most professional, leak-free result.

Yes, the VOP0262 is a universal component designed to work with all standard 3-inch pellet vent systems and is compatible with most pellet stove brands and models that have a 3-inch flue outlet. It accommodates appliances burning wood pellets, corn, oil, and various biofuels. However, always verify your specific appliance manufacturer's venting requirements and confirm that horizontal through-wall venting is an approved configuration for your model.

The VOP0262 requires a minimum 1-inch air space clearance from the outer wall of the vent pipe to any combustible materials. This clearance is mandated by both U.S. (NFPA 211) and Canadian (CSA B365) building codes and must be maintained throughout the entire installation. When cutting the wall opening, account for this clearance plus the outer diameter of the pass-thru assembly. Always consult local building authorities and follow all manufacturer installation guidelines.

Yes, the VOP0262 can be installed through walls with vinyl, aluminum, wood, or other common siding materials. However, for vinyl or aluminum siding installations, it's highly recommended to use a dedicated siding trim kit. These trim kits provide proper water management, accommodate the siding profile, create a professional finished appearance, and ensure that the siding isn't compressed or damaged during installation. The trim kit installs between the pass-thru and the siding for optimal weatherproofing.

The VOP0262 wall pass-thru is one component of a complete pellet venting system. For a typical installation, you'll also need: pellet vent pipe sections to connect from the stove to the wall pass-thru, an appliance adapter to connect pipe to your stove, a horizontal termination cap for the exterior vent outlet, appropriate support brackets if required, and potentially a siding trim kit if you have vinyl or aluminum siding. Always plan your complete venting system before beginning installation and consult with a qualified professional if needed.

The VOP0262 is covered under the manufacturer's limited lifetime warranty program, typically providing 100% replacement coverage for 15 years from the original purchase date, then 50% coverage thereafter. Warranty coverage requires professional installation according to manufacturer specifications, proper annual maintenance, burning only approved fuels, and keeping proof of purchase and product registration. The black finish may have separate coverage terms. Note that labor and installation costs are not included in warranty coverage. Always register your product and retain documentation.
